Elevate your Switch Game
Enterprise • Office • Home
Mobile App
Monitor and manage your network from anywhere in the world from your mobile device.
Gig and Multi-Gig Switching Capacity
The Alta Labs switches offer Gigabit connectivity and our 24-port switch supports up to 10 Gbps
Intuitive VLAN and Device Configuration
Intuitive VLAN and device configuration using the Alta Cloud Management platform
Download and Upload Rate Limiting
Inbound and outbound traffic can be limited to a portion of the available bandwidth per connection.
PoE Flexibility
Whether you have a SOHO environment or an enterprise network, Alta Labs switches are designed to meet your needs.
Mounting Flexibility
The S24-PoE and S16-PoE include rack ears that can be connected to the switches for rack installation or mounting on a wall.
The S24-PoE and S16-PoE switchesinclude the Rackstud™ DUO toolless rackmount system.
The S8-PoE switch has padding for desktop placement and notches for mounting on the included wall‑mount bracket.
Which Switch Is Right for You?
S16-POE
Interface ports
PoE+ Ports
SFP Ports
PoE Budget
S8-POE
8
4
N/A
60 W
S16-POE
16
8
2 SFP
120 W
S24-POE
24
16
2 SFP+
240 W
Which Switch Is Right for You?
S8-POE
8
Interface ports
4
PoE+ Ports
N/A
SFP Ports
60 W
PoE Budget
S16-POE
16
Interface ports
8
PoE+ Ports
2 SFP
SFP Ports
120 W
PoE Budget
S24-POE
24
Interface ports
16
PoE+ Ports
2 SFP+
SFP Ports
240 W
PoE Budget
Specifications
Network Ports
S8-POE
S16-POE
S24-POE
Interface ports
(8)
10/100/1000 Mbps
(16)
10/100/1000 Mbps
(24)
10/100/1000 Mbps
SFP/SFP+
None
(2) SFP
(2) SFP+
Switching Capacity
16 Gbps
36 Gbps
88 Gbps
Non-blocking Throughput
8 Gbps
18 Gbps
44 Gbps
Forwarding Rate
11.9 Gbps
26.8 Gbps
65.5 Gbps
PoE Budget/Max
60 Watts
120 Watts
240 Watts
PoE Supply
30 Watts per port
30 Watts per port
30 Watts per port
Forwarding Rate
(4) 802.3 at PoE+
(8) 802.3 at PoE+
(16) 802.3 at PoE+
Non-PoE Ports
(4)
(10)
(10)
Per Port Leds
PoE
Orange
Orange
Orange
Network
Orange: 10/100 Mbps,
Blue: 1000Mbps
Orange: 10/100 Mbps,
Blue: 1000Mbps
Orange: 10/100 Mbps,
Blue: 1000Mbps
SFP/SFP+
None
Blue - Link/Activity
(1000 Mbps)
Blue - Link/Activity (1000 Mbps, 2500 Mbps, 5000Mbps)
White - Link/Activity (10 Gbps)
Packet Buffer
4.1Mbit
4.1Mbit
12Mbit
Mac Table Size
8K
8K
16K
Energy Efficient Ethernet
Yes
Yes
Yes
Management
Factory reset button
Factory reset button
Factory reset button
Enclosure
Dimensions
25.7mm x 91mm x 180mm
44mm x 254 mm x 441.5 mm
44mm x 254 mm x 441.5 mm
Material Type
Injection molded plastic
SGCC
SGCC
Material Finish
Matte
Powder coat - Matte
Powder coat - Matte
Color
White
Metalic gray
Metalic gray
Mounting Options
Locking wall mount
Rack mount
Rack mount
Weight
.38 kg (.83 lbs)
3.6 kg (7.9 lbs)
3.6 kg (7.9 lbs)
Environmental
Operating Temp
-5 to 50° C
-5 to 50° C
-5 to 50° C
Operating Humidity
10 - 90%
Non condensing
10 - 90%
Non condensing
10 - 90%
Non condensing
IP Rating
None
None
None
EMI Rating
EMI Class-B with 3dB margin
EMI Class-A with 3dB margin
EMI Class-A with 3dB margin
Cooling Fan
None
None
None
Device Setup
Chipset
Realtek
Realtek
Realtek
Bluetooth
Yes - Setup
Yes - Setup
Yes - Setup
Power & Protection
w/o PoE
8 Watts
23 Watts
53 Watts
Full PoE
68 Watts
143 Watts
295 Watts
Power Supply
Universal AC, 100 - 240VAC 50/60Hz External
Universal AC, 100 -240VAC 50/60Hz Internal
Universal AC, 100 -240VAC 50/60Hz Internal
RJ45 Port Surge Protection
12kV forESD - contact,
25kV forESD - Air
12kV forESD - contact,
25kV forESD - Air
12kV forESD - contact,
25kV forESD - Air
Certifications
Certifications
FCC, CE, IC
FCC, CE, IC
FCC, CE, IC
